Tenum Family of Thermal Camera Cores

Unrivaled. Uncompromised.

A New Frontier in Infrared Technology in a 10-Micron Uncooled Thermal Core.

With unrivaled design and unwavering performance, Tenum® precisely balances ultra-small pixel structure with ultra-sensitive microbolometer performance at a remarkable cost advantage.

Tenum 640 Thermal Camera Core

The 10-micron pixel pitch Vanadium Oxide (VOx) technology behind Leonardo DRS’ Tenum® is the most advanced uncooled infrared sensor design available to Original Equipment Manufacturers (OEMs) today.

Integration is easy with a Development Kit including:

  • User manual which describes the operation, interfaces, and timing
  • Interface schematics and detailed pin out description
  • Mechanical assembly and integration files
  • Interface-control document which describes the registers and how to configure the camera
  • Camera-control software for Windows
  • Custom lens calibration guide to support optional no-lens configuration
  • Superior customer service support

Tenum®  640

With unrivaled design and unwavering performance, Tenum®  640 precisely balances ultra-small pixel structure with ultra-sensitive microbolometer performance at a remarkable cost advantage. The 10-micron pixel pitch Vanadium Oxide (VOx) technology behind Leonardo DRS’ Tenum®  640 iss the most advanced uncooled infrared sensor design available to original equipment manufacturers (OEMs) today.

Tenum®  1280

The 10-micron technology behind the all new Tenum® 1280 puts Leonardo DRS significantly ahead of its competitors in the race to smaller pixel pitch and lower cost products among manufacturers of infrared detectors. The Tenum® 1280 is the first high-resolution 10-micron thermal camera core from Leonardo DRS.

Tenum®  1280M

The 10-micron technology behind the Tenum® 1280M puts Leonardo DRS significantly ahead of its competitors in the race to smaller pixel pitch and lower cost products among manufacturers of infrared detectors. The Tenum® 1280M is part of the high-resolution 10-micron family of thermal camera modules from Leonardo DRS.
