SHINCOM 3100

Control and manage every aspect of shipboard communications onboard or ashore.

Shipboard Integrated Communications System

Reliable Technology for Mission-Critical Naval Communications

Integrating tactical, administrative, voice and data communications, SHINCOM 3100 all-digital secure voice system (SVS) interfaces, controls and manages every aspect of internal and external communications. The system architecture ensures continuity of communications in very adverse conditions with multiple levels of built-in redundancy and internal battery backup.

Furthermore, the SHINCOM 3100 terminal equipment enables commanders and operators to communicate on multiple channels simultaneously without increased workload. In fact, the channels incorporate Two Ears – Four Voices® 3D spatial audio technology with radio noise reduction to further minimize their fatigue.

SVS can provide the communications architecture for either new-build platforms or legacy systems. It is backwards compatible to provide improved capability and capacity, replacing legacy secure voice systems, tactical intercom systems and ship’s service telephone systems.

 Highlights

CENTRAL SWITCHING UNIT

  • Highly scalable up to hundreds of connections
  • Extensive command and control communication features
  • Executive Committee (EXCOMM) radio / cypher patching
  • Multilevel Precedence and Preemption (MLPP) plus programmable accesses, restrictions and overrides
  • Commercial Off-The-Shelf (COTS) open standards architecture
  • Redundant and independent non-blocking 4096 channel Red and 4096 channel Black switching

  • Internal high-capacity plain and secure conference bridges up to 4096 channels each (2048 conferences)
  • Voice over Internet Protocol (VoIP) voice switching – Session Initiation Protocol (SIP) with MLPP
  • Enhanced Private Branch eXchange (PBX) calling features
  • Redundant, hot-swapping architecture
  • Integrated VoIP and Integrated Services Digital Network (ISDN)
  • VITA Portable eXtended (VPX) integrated backplane

E1 TERMINALS

  • Up to 8 active and 8 on-hold channels
  • All digital, extensive digital signal processing
  • Field-proven, rugged, drip-proof
  • Hybrid touch screen and key technology
  • Centralized graphics displays
  • Auto-muting secure / non-secure
  • Visual and audio Press-to-Talk (PTT) / security status indication
  • Supports both internal and / or external speakers

OAM Console

  • Graphical User Interface for system configuration
  • CommPlan and data base setup and control

Leonardo DRS, Inc. announced today the delivery of its first next-generation Integrated Voice Communication Systems (IVCS).

Read the press release

After 50 years, we continue to deliver our high standard of work to our customers, while adapting to current circumstances and prioritizing the safety of our employees.

Learn more

Request Information

Looking for more information on SHINCOM 3100? We would like to hear from you.
